Intel Stratix 10 TX Devices
In addition to delivering over 8 Tbps of transceiver bandwidth in a single package,
Intel Stratix 10 TX devices offer up to 1 GHz core fabric performance and contain up
to 2.8 million LEs in a monolithic fabric. They also feature up to 144 general purpose
transceivers on separate transceiver tiles, and 2666 Mbps DDR4 external memory
interface performance. The dual mode transceivers are capable of data rates up to
57.8 Gbps PAM4 / 28.9 Gbps NRZ for both short reach and backplane driving
applications. Select devices contain an embedded hard processor system (HPS) based
on an application-class quad-core 64 bit Arm Cortex-A53, running at clock rates up to
1.5 GHz.
These devices are optimized for FPGA applications that require the highest transceiver
bandwidth, and the highest core fabric performance, with the power efficiency of
Intel’s 14 nm tri-gate process technology.
1. Intel® Stratix® 10 TX Device Overview
683717 | 2022.08.18
Intel® Stratix® 10 TX Device Overview Send Feedback
The high-performance monolithic FPGA fabric is based on the new Intel Hyperflex core
architecture that includes additional Hyper-Registers everywhere throughout the
interconnect routing and at the inputs of all functional blocks. The core fabric also
contains an enhanced logic array utilizing Intel’s adaptive logic module (ALM) and a
rich set of high performance building blocks including:
• eSRAM (47.25 Mbit) embedded memory blocks (available in select devices)
• M20K (20 Kb) embedded memory blocks
• Variable precision DSP blocks with IEEE 754 compliant hard floating-point
• Fractional synthesis and integer PLLs
• Hard memory controllers and PHY for external memory interfaces
• General purpose IO cells
