    MSP430F437IPZ MCU Microcontroller Flash SPI UART Surface Mount 16Bit 8MHz

    Ask Lasest Price
    Brand Name : TI
    Model Number : MSP430F437IPZ
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 999999
    Delivery Time : 1 - 3 days
    • Product Details
    • Company Profile

    MSP430F437IPZ MCU Microcontroller Flash SPI UART Surface Mount 16Bit 8MHz

    MSP430F437IPZ MCU Microcontroller
    Unit IC 100-LQFP Package Flash SPI UART Surface Mount 16Bit 8MHz

    MSP430F437IPZ


    Product Status
    Active
    Core Processor
    MSP430 CPU16
    Core Size
    Speed
    8MHz
    Connectivity
    SPI, UART/USART
    Peripherals
    Brown-out Detect/Reset, LCD, POR, PWM, WDT
    Number of I/O
    48
    Program Memory Size
    Program Memory Type
    FLASH
    EEPROM Size
    -
    RAM Size
    1K x 8
    Voltage - Supply (Vcc/Vdd)
    1.8V ~ 3.6V
    Data Converters
    A/D 8x12b
    Oscillator Type
    Internal
    Operating Temperature
    -40°C ~ 85°C (TA)
    Mounting Type
    Surface Mount
    Package / Case
    100-LQFP
    Supplier Device Package
    100-LQFP (14x14)
    Base Product Number

    Description


    MSP430F437IPZ IC MCU 16BIT 32KB FLASH 100LQFP



    Detailed Description


    MSP430F437IPZ MSP430 CPU16 MSP430x4xx Microcontroller IC 16-Bit 8MHz 32KB (32K x 8 + 256B) FLASH 100-LQFP (14x14)


    • Five Power Saving Modes
    • Wake-Up From Standby Mode in Less Than 6 µs
    • 16-Bit RISC Architecture, 125-ns Instruction Cycle Time
    • 12-Bit A/D Converter With Internal Reference, Sample-and-Hold and
    • Autoscan Feature
    • 16-Bit Timer_B With Three(1) or Seven(2) Capture/Compare-With-Shadow Registers
    • 16-Bit Timer_A With Three Capture/Compare Registers
    • On-Chip Comparator
    • Serial Communication Interface (USART), Select Asynchronous UART or
    • Synchronous SPI by Software:
    • Two USARTs (USART0, USART1)(1)
    • One USART (USART0)(2)
    • Brownout Detector
    • Supply Voltage Supervisor/Monitor With Programmable Level Detection
    • Serial Onboard Programming, No External Programming Voltage Needed
    • Programmable Code Protection by Security Fuse
    • Integrated LCD Driver for up to 160 Segments
    • Bootstrap Loader
    • Family Members Include:
    • MSP430F435, MSP430F4351(3):
    • 16KB+256B Flash Memory
    • 512B RAM
